Ford S-MAX II facelift 2.5 CVT (190 hp)

General information

1655
1916
4804
Brand
Ford
Model
S-MAX
Vehicle class
M
Body type
Minivan
Doors
5
Seats
5, 7
Width
1916 mm
Length
4804 mm
Height
1655 mm
Wheelbase
2850 mm
Front track
1606 mm
Rear track
1606 mm
Trunk
1035 l
Maximum amount of Luggage
2200 l
Ground clearance
141 mm
Engine type
Hybrid
Engine position
Front, transverse
Engine capacity
2488 cm³
Power
190 hp at 5500 rpm
Power, kW
140 kW
Torque
200 Nm
Fuel injection
distributed injection (multi-point)
Boost
no
Cylinder arrangement
Inline
Number of cylinders
4
Valves per cylinder
4
Fuel type
95
Bore and stroke
89 × 100 mm
Compression ratio
13
Battery capacity, kW/h
1.1
CO2 Emissions, g/km
128 g/km
Emission standard
Euro 6
Front suspension
Independent, spring
Rear suspension
Independent, spring
Type of gearbox
Variable
Drive wheel
Front wheel drive
Front brakes
Ventilated disc
Rear brakes
Disc
Maximum speed
185 km/h
Acceleration (0-100 km/h)
98 sec
Fuel consumption urban
6.3 l
Fuel consumption extra-urban
5.2 l
Fuel consumption combined
5.6 l
Weight
1902 kg
Full mass
2545 kg
Fuel tank
65 l
Tires size
235/55/R17, 235/50/R18, 245/45/R19
