Ford Transit Connect II facelift 1.5 AT (120 hp)

General information

1861
1835
4418
Brand
Ford
Model
Transit Connect
Body type
Van
Doors
5
Seats
3
Width
1835 mm
Length
4418 mm
Height
1861 mm
Wheelbase
2662 mm
Front track
1568 mm
Rear track
1585 mm
Trunk
3200 l
Maximum amount of Luggage
3200 l
Ground clearance
159 mm
Vehicle class
M
Engine type
Diesel
Engine position
Front, transverse
Engine capacity
1498 cm³
Power
120 hp at 3600 rpm
Power, kW
120 kW
Torque
270 Nm
Boost
Turbocharging
Cylinder arrangement
Inline
Number of cylinders
4
Fuel type
Diesel
Emission standard
Euro 5
Bore and stroke
73.5x88.3 mm
Valves per cylinder
2
Compression ratio
16
Front suspension
Independent, spring
Rear suspension
semi-independent, spring
Type of gearbox
Automatic
Number of gears
8
Drive wheel
Front wheel drive
Front brakes
Ventilated disc
Rear brakes
Disc
Tires size
205/60/R16
